Product Summary

The FSA266K8X is an ultra high-speed (UHS) dual single-pole/single-throw (SPST) analog switch. The device is fabricated with advanced sub-micron CMOS technology to achieve high speed enable and disable times and low On Resistance over a broad VCC range. The FSA266K8X is specified to operate over the 1.65 to 5.5V VCC operating range. The device is organized as a dual switch with independent CMOS compatible switch enable (OE) controls.

Parametrics

FSA266K8X absolute maximum ratings: (1)Supply Voltage (VCC): -0.5V to +7.0V; (2)DC Switch Voltage (VS): -0.5V to VCC+0.5V; (3)DC Input Voltage (VIN): -0.5V to +7.0V; (4)DC Input Diode Current @ (IIK) VIN < 0V: -50 mA; (5)DC Switch Output Current (IOUT): ±128 mA; (6)DC VCC or Ground Current (ICC/IGND): ±100 mA; (7)Storage Temperature Range (TSTG): -65℃ to +150℃; (8)Junction Lead Temperature under Bias (TJ): +150℃; (9)Junction Lead Temperature (TL) (Soldering, 10 Seconds): +260℃; (10)Power Dissipation (PD) @ +85℃: 250 mW.

Features

FSA266K8X features: (1)Useful in both analog and digital applications; (2)Space saving US8 surface mount package; (3)MicroPak Pb-Free leadless package; (4)Typical 7Ω On Resistance @ 5V VCC; (5)Broad VCC operating range: 1.65V to 5.5V; (6)Rail-to-Rail signal handling; (7)Power down high impedance control inputs; (8)Control inputs are overvoltage tolerant; (9)Control inputs are CMOS compatible; (10)>300 MHz-3dB bandwidth.

Diagrams

FSA266K8X connection diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
FSA266K8X
FSA266K8X
Fairchild Semiconductor
Analog Switch ICs LV Dual SPST Normally Open Analog
Data Sheet
0-1: $0.35
1-25: $0.25
25-100: $0.21
100-250: $0.18
FSA266K8X_Q
FSA266K8X_Q
Fairchild Semiconductor
Analog Switch ICs LV Dual SPST Normally Open Analog
Data Sheet
Negotiable
